Flush-mounted time-controlled 1300W electronic toggle relay module for UP radio system, with neutral wire
Model:4820406
Type:Actuators
Product Specifications:
- Dimensions (LxHxD): 44.1 x 34.7 x 18.5 mm
- Network voltage: 230 V~(±15%)- 50 Hz
- Power on load: 5.6A – 1300W (resistive); 2.8A – 690VA (other loads)
- Consumption in standby mode: < 0.8VA – < 0.4W
- Room temperature: – -20°C to 60°C
- Relative humidity: 0 to 90%
- IP protection rating: IP30
- Audio level: <60dB at 20cm
- Range: 250m in free field of view and without obstacles. Range is reduced by metal items, walls or partitions
- Radio protocol: Zigbee
- Maximum transmitted radio power: 10 mW
- Radio frequency band: 2400.0 – 2483.5 MHz
