Flush-mounted time-controlled 300W electronic dimmer module for UP Radio system, with neutral wire
Model:4820408
Type:Actuators
Product Specifications:
- Dimensions (LxHxD): 40 x 45.7 x 13.1 mm
- Network voltage: 230 V~(±15%)- 50 Hz
- Power on load: 1.3A – 300W (resistive); 0.6A – 125VA (other loads)
- Consumption in standby mode: < 0.8VA – < 0.4W
- Room temperature: – -20°C to 40°C
- Relative humidity: 0 to 90%
- IP protection rating: IP30
- Range: 250m in free field of view and without obstacles. Range is reduced by metal items, walls or partitions
- Radio protocol: Zigbee
- Maximum transmitted radio power: 10 mW
- Radio frequency band: 2400.0 – 2483.5 MHz
